Weak TLS cipher suites
HTTP and HTTPS are well known Internet protocols that don’t require any introduction. The other day at work as part of a daily security scan one of our servers got tagged as using weak cipher suites during TLS negotiation. In this quick post I’ll explain what a weak cipher suite means and how to fix it.
There are many tools out there to check if you are following the security best practices when it comes to SSL/TLS server configuration (supported versions, accepted cipher suites, certificate transparency, expiration, etc.) but one of my favorites is https://www.ssllabs.com/ssltest/analyze.html and drwetter/testssl.sh.
SSLlabs.com is easy to use, you just have to enter a Hostname and the website will analyze all possible TLS configuration and calculate a score for you, this tool will also tell you what you can do to improve that score.
There are many TLS protocol versions: 1.0, 1.1, 1.2, 1.3. The first two are considered insecure and should not be used so I will focus on 1.2 and 1.3 only.
In my case SSLlabs.com was complaining about weak cipher suites were supported for TLS 1.2:
The above report is showing ECDHE-RSA-AES256-SHA384E and ECDHE-RSA-AES256-SHA as weak cipher suites.
First let’s clarify a couple of things, according to Wikipedia:
Cipher suite: A set of algorithms that help secure a network connection.
So a weak cipher suite will be algorithms with known vulnerabilities that can be used by attackers to downgrade connections or other nefarious things.
Fixing this is very easy and will require changing a line or two on the server configuration, deploying the changes and then testing again using SSLlabs.com.
Of course, the above only applies if you know exactly what you are doing, otherwise it will take you many attempts and you are going to waste precious time.
Reproduce and fix the issue locally
Suppose you have the same issue I had, because this issue was reported on an Nginx Server now the task is to reproduce the issue locally and come up with a fix. With modern technologies like docker containers it’s very easy to run a local Nginx server, the only thing you need is a copy of the nginx.conf, to run a docker container the command will be:
docker run --name mynginx -v ./public.pem:/etc/nginx/public.pem -v ./private.pem:/etc/nginx/private.pem -v ./nginx.conf:/etc/nginx/nginx.conf:ro -p 1337:443 --rm nginx
The above command is telling docker to run an Nginx container; binding the local port 1337 to the container port 443 and also mounting the public.pem (public key), private.pem (private key) and nginx.conf (the server configuration) files inside the container.
The nginx.conf looks like this:
server {
listen 443 ssl;
server_name www.alevsk.com;
ssl_certificate /etc/nginx/public.pem;
ssl_certificate_key /etc/nginx/private.pem;
ssl_protocols TLSv1.3 TLSv1.2;
ssl_prefer_server_ciphers on;
ssl_ecdh_curve secp521r1:secp384r1:prime256v1;
ssl_ciphers EECDH+AESGCM:EECDH+AES256:EECDH+CHACHA20;
ssl_session_cache shared:TLS:2m;
ssl_buffer_size 4k;
add_header Strict-Transport-Security 'max-age=31536000; includeSubDomains; preload' always;
}
You can test the server is working fine with a simple curl command:
curl https://localhost:1337/ -v -k
* Trying 127.0.0.1:1337...
* Connected to localhost (127.0.0.1) port 1337 (#0)
* ALPN, offering h2
* ALPN, offering http/1.1
* CAfile: /etc/ssl/certs/ca-certificates.crt
* CApath: /etc/ssl/certs
* TLSv1.0 (OUT), TLS header, Certificate Status (22):
* TLSv1.3 (OUT), TLS handshake, Client hello (1):
* TLSv1.2 (IN), TLS header, Certificate Status (22):
* TLSv1.3 (IN), TLS handshake, Server hello (2):
* TLSv1.2 (OUT), TLS header, Finished (20):
* TLSv1.3 (OUT), TLS change cipher, Change cipher spec (1):
* TLSv1.2 (OUT), TLS header, Certificate Status (22):
* TLSv1.3 (OUT), TLS handshake, Client hello (1):
* TLSv1.2 (IN), TLS header, Finished (20):
* TLSv1.2 (IN), TLS header, Certificate Status (22):
* TLSv1.3 (IN), TLS handshake, Server hello (2):
* TLSv1.2 (IN), TLS header, Supplemental data (23):
* TLSv1.3 (IN), TLS handshake, Encrypted Extensions (8):
* TLSv1.2 (IN), TLS header, Supplemental data (23):
* TLSv1.3 (IN), TLS handshake, Certificate (11):
* TLSv1.2 (IN), TLS header, Supplemental data (23):
* TLSv1.3 (IN), TLS handshake, CERT verify (15):
* TLSv1.2 (IN), TLS header, Supplemental data (23):
* TLSv1.3 (IN), TLS handshake, Finished (20):
* TLSv1.2 (OUT), TLS header, Supplemental data (23):
* TLSv1.3 (OUT), TLS handshake, Finished (20):
* SSL connection using TLSv1.3 / TLS_AES_256_GCM_SHA384
* ALPN, server accepted to use http/1.1
* Server certificate:
....
....
....
>
* TLSv1.2 (IN), TLS header, Supplemental data (23):
* TLSv1.3 (IN), TLS handshake, Newsession Ticket (4):
* TLSv1.2 (IN), TLS header, Supplemental data (23):
* TLSv1.3 (IN), TLS handshake, Newsession Ticket (4):
* old SSL session ID is stale, removing
* TLSv1.2 (IN), TLS header, Supplemental data (23):
* Mark bundle as not supporting multiuse
< HTTP/1.1 404 Not Found
< Server: nginx
< Date: Sun, 15 May 2022 23:14:23 GMT
< Content-Type: text/html
< Content-Length: 146
< Connection: keep-alive
< Strict-Transport-Security: max-age=31536000; includeSubDomains; preload
<
404 Not Found
404 Not Found
nginx
* Connection #0 to host localhost left intact
The next step is to reproduce the report from https://www.ssllabs.com/ but that will involve somehow exposing our local Nginx server to the internet and that’s time consuming. Fortunately there’s an amazing open source tool that will help you to run all these TLS tests locally.
drwetter/testssl.sh is a tool for testing TLS/SSL encryption anywhere on any port and the best part is that runs on a container too, go to your terminal again and run the following command:
docker run --rm -ti --net=host drwetter/testssl.sh localhost:1337
The above command will run the drwetter/testssl.sh container, the –rm flag will automatically delete the container once it’s done running (keep your system nice and clean), -ti means interactive mode and –net=host will allow the container to use the parent host network namespace.
After a couple of seconds you will see a similar result as in the website, something like this:
Testing server’s cipher preferences.
Hexcode Cipher Suite Name (OpenSSL) KeyExch. Encryption Bits Cipher Suite Name (IANA/RFC)
-----------------------------------------------------------------------------------------------------------------------------
SSLv2
-
SSLv3
-
TLSv1
-
TLSv1.1
-
TLSv1.2 (server order)
xc030 ECDHE-RSA-AES256-GCM-SHA384 ECDH 521 AESGCM 256 TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384
xc02f ECDHE-RSA-AES128-GCM-SHA256 ECDH 521 AESGCM 128 TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256
xc028 ECDHE-RSA-AES256-SHA384 ECDH 521 AES 256 TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384
xc014 ECDHE-RSA-AES256-SHA ECDH 521 AES 256 TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA
xcca8 ECDHE-RSA-CHACHA20-POLY1305 ECDH 521 ChaCha20 256 TLS_ECDHE_RSA_WITH_CHACHA20_POLY1305_SHA256
TLSv1.3 (server order)
x1302 TLS_AES_256_GCM_SHA384 ECDH 256 AESGCM 256 TLS_AES_256_GCM_SHA384
x1303 TLS_CHACHA20_POLY1305_SHA256 ECDH 256 ChaCha20 256 TLS_CHACHA20_POLY1305_SHA256
x1301 TLS_AES_128_GCM_SHA256 ECDH 256 AESGCM 128 TLS_AES_128_GCM_SHA256
Even on this test we see the weak cipher suites (ECDHE-RSA-AES256-SHA384 and ECDHE-RSA-AES256-SHA).
Great, now you are able to fully reproduce the issue locally and test as many times as you want until you have the perfect configuration. It’s time to do the actual fix.
Open the nginx.conf file one more time and locate the line that starts with ssl_ciphers and just add !ECDHE-RSA-AES256-SHA384:!ECDHE-RSA-AES256-SHA at the end, ie:
server {
listen 443 ssl;
server_name www.alevsk.com;
ssl_certificate /etc/nginx/public.pem;
ssl_certificate_key /etc/nginx/private.pem;
ssl_protocols TLSv1.3 TLSv1.2;
ssl_prefer_server_ciphers on;
ssl_ecdh_curve secp521r1:secp384r1:prime256v1;
ssl_ciphers EECDH+AESGCM:EECDH+AES256:EECDH+CHACHA20:!ECDHE-RSA-AES256-SHA384:!ECDHE-RSA-AES256-SHA;
ssl_session_cache shared:TLS:2m;
ssl_buffer_size 4k;
add_header Strict-Transport-Security 'max-age=31536000; includeSubDomains; preload' always;
}
If you run the Nginx container with the new configuration and then run the drwetter/testssl.sh test again this time you will see no weak cipher suites anymore.
TLSv1.2 (server order)
xc030 ECDHE-RSA-AES256-GCM-SHA384 ECDH 521 AESGCM 256 TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384
xc02f ECDHE-RSA-AES128-GCM-SHA256 ECDH 521 AESGCM 128 TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256
xcca8 ECDHE-RSA-CHACHA20-POLY1305 ECDH 521 ChaCha20 256 TLS_ECDHE_RSA_WITH_CHACHA20_POLY1305_SHA256
TLSv1.3 (server order)
x1302 TLS_AES_256_GCM_SHA384 ECDH 256 AESGCM 256 TLS_AES_256_GCM_SHA384
x1303 TLS_CHACHA20_POLY1305_SHA256 ECDH 256 ChaCha20 256 TLS_CHACHA20_POLY1305_SHA256
x1301 TLS_AES_128_GCM_SHA256 ECDH 256 AESGCM 128 TLS_AES_128_GCM_SHA256
Conclusion
Congratulations, you just fixed your first security engineer issue and now you can push the fix to production. In general when it comes to fixing any kind of problem in tech it is better to start by reproducing the issue locally and work on a fix from there (of course this is debatable if you are facing an issue that only happens in a specific environment). SSL/TLS and cipher suites are one of those technologies that you have to learn by heart or at least have a very good understanding if you want to work in application security, but not only that, once you understand it it will completely change the way you approach problems and debug security applications .
Happy hacking.
